| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
2,900 pcs
|
2900 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request | |
|
22 pcs
|
22 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request | |
|
4 pcs
|
4 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Style | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Thickness | |
| Contact Type | |
| Current Rating (Amps) | |
| Features | |
| Flange Feature | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Number of Rows | |
| Shell Material, Finish | |
| Shell Size, Connector Layout | |
| Termination | |
| Termination Style |
The TE Connectivity 5-747908-2 is a 15-position D-Sub plug (male pin) connector from the AMPLIMITE series, designed for free hanging (in-line) mounting. It features solder cup termination for secure wire connections, making it suitable for cable assembly applications.
This connector uses signal contacts with a gold finish (8.00 µin thickness) for reliable low-level signal transmission and corrosion resistance. The shell is made of steel with a tin plating, and includes grounding indents for improved EMI performance. The shell size is 2 (DA, A).
Rated at 3A per contact, this connector is appropriate for moderate-current signal interfaces. The insulator material has a UL94 V-0 flammability rating, ensuring compliance with fire safety requirements in electronic equipment. The unthreaded housing/shell flange simplifies mounting in panel or cable applications.
| Qty | Low | High |
|---|---|---|
| 1+ | $4.30 | $4.30 |
| 10+ | $3.94 | $3.94 |
| 25+ | $3.79 | $3.79 |
| 50+ | $3.73 | $3.73 |
| 100+ | $3.60 | $3.60 |
| 250+ | $3.41 | $3.41 |
| 500+ | $3.33 | $3.33 |
| 1,000+ | $3.19 | $3.19 |
| 2,500+ | $3.13 | $3.13 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
It has 15 positions arranged in 2 rows.
Solder cup termination.
3 Amps per contact.
Gold, with a thickness of 8.00 µin (0.203 µm).
Steel, tin plated.
UL94 V-0.
The data indicates RoHS3 compliance, but this is unverified.
