| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
160 pcs
|
160 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| China RoHS | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Thickness | |
| Contact Length | |
| Contact Material | |
| Contact Shape | |
| Contact Type | |
| Current Rating (Amps) | |
| EU ELV | |
| Fastening Type | |
| Features | |
| Halogen Free | |
| Insulation Color | |
| Insulation Height | |
| Insulation Material | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Operating Temperature | |
| Pitch | |
| Shrouding | |
| Solder Process Capability | |
| Style | |
| Tape & Reel | |
| Termination | |
| Termination Style |
The TE Connectivity 5-147324-7 is an 8 position single row shrouded header from the MTE series. It features a 2.54mm (0.100") pitch and is designed for board-to-board or cable applications. The connector uses surface mount right angle termination with solder contacts.
The header has a 4-wall shrouded design with a latch holder fastening system for secure mating. Contacts are made of brass with a tin finish (100.0µin thickness) and a square contact shape. The insulation is black thermoplastic rated UL94 V-0.
Electrical rating is 3A with an operating temperature range of -65°C to 105°C. Additional features include board lock, keying slot, and solder retention. The component is reflow solder capable to 260°C.
| Qty | Low | High |
|---|---|---|
| 1+ | $3.80 | $3.80 |
| 10+ | $3.23 | $3.23 |
| 100+ | $2.77 | $2.77 |
| 300+ | $2.67 | $2.67 |
| 600+ | $2.55 | $2.55 |
| 900+ | $2.18 | $2.18 |
| 2,400+ | $2.13 | $2.13 |
| 4,800+ | $2.10 | $2.10 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
8 positions in a single row, all positions loaded.
2.54mm (0.100").
3A.
Surface mount, right angle.
Yes, it is EU RoHS compliant per Directive 2011/65/EU.
-65°C to 105°C.
Tin, 100.0µin (2.54µm) thickness.
