| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
192 pcs
|
192 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Thickness | |
| Contact Material | |
| Contact Shape | |
| Contact Type | |
| Current Rating (Amps) | |
| Fastening Type | |
| Features | |
| Insulation Color | |
| Insulation Height | |
| Insulation Material | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Operating Temperature | |
| Pitch | |
| Row Spacing | |
| SVHC Present | |
| Shrouding | |
| Style | |
| Tape & Reel | |
| Termination |
The TE Connectivity 5-104894-1 is a 10-position, 2-row shrouded header from the 50/50 Grid family, designed for board-to-board applications. This male pin connector features a 1.27mm pitch with right angle surface mount termination.
Key specifications include brass contacts with tin finish (30µin thickness), LCP (Liquid Crystal Polymer) insulator rated UL94 V-0, and operating temperature range of -65°C to 105°C. The connector is shrouded - 4 wall with push-pull fastening, includes board lock and solder retention features for secure mounting.
This part is a lead-free RoHS compliant substitute per TE PCN-25-265732. The insulation height is 5.40mm (0.213"), row spacing is 1.27mm, and all 10 positions are loaded. The connector has an MSL of 1 Unlimited and is REACH unaffected.
Designed for automated assembly with SMD compatibility, the 5-104894-1 is suitable for dense PCB layouts requiring a reliable, compact board-to-board interconnect.
| Qty | Low | High |
|---|---|---|
| 1+ | $7.33 | $7.33 |
| 10+ | $7.06 | $7.06 |
| 25+ | $5.90 | $5.90 |
| 50+ | $5.62 | $5.62 |
| 96+ | $5.59 | $5.59 |
| 512+ | $5.11 | $5.11 |
| 1,024+ | $3.96 | $3.96 |
| 2,528+ | $3.85 | $3.85 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
10 positions in 2 rows, all positions loaded.
1.27mm (0.050") pitch.
0.5A per contact.
Surface mount, right angle.
-65°C to 105°C.
Liquid Crystal Polymer (LCP), rated UL94 V-0.
Yes, this is a lead-free RoHS compliant substitute per PCN-25-265732.
