| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
49 pcs
|
49 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request | |
|
8 pcs
|
8 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Thickness | |
| Contact Length | |
| Contact Length - Mating | |
| Contact Material | |
| Contact Shape | |
| Contact Type | |
| Fastening Type | |
| Features | |
| Insulation Color | |
| Insulation Height | |
| Insulation Material | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Operating Temperature | |
| Pitch | |
| Row Spacing | |
| Shrouding | |
| Style | |
| Tape & Reel | |
| Termination | |
| Voltage Rating |
The TE Connectivity AMPMODU System 50 header (5-104069-5) is a 30-position, dual-row male pin connector designed for board-to-board or cable applications. It features a 1.27mm pitch and a right-angle through-hole mounting style with solder termination.
The header is shrouded with a 2-wall design and includes a latch holder for secure mating. The insulation is black thermoplastic rated UL94 V-0, with an insulation height of 7.37mm. Contacts are made of copper alloy with a tin finish and thickness of 30.0µin. The mating contact length is 3.18mm and the contact shape is circular.
Rated for 30VAC, the component operates over a temperature range of -65°C to 105°C. A board guide feature aids in alignment during assembly. All 30 positions are loaded with male pins arranged in two rows spaced at 2.54mm.
| Qty | Low | High |
|---|---|---|
| 1+ | $10.84 | $10.84 |
| 10+ | $7.89 | $7.89 |
| 20+ | $7.69 | $7.69 |
| 260+ | $7.45 | $7.45 |
| 500+ | $6.93 | $6.93 |
| 1,000+ | $6.11 | $6.11 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The pitch is 1.27mm (0.050").
It has 30 positions arranged in 2 rows.
Through Hole, Right Angle.
30VAC.
-65°C to 105°C.
Tin with a thickness of 30.0µin (0.76µm).
It is marked as RoHS3 Compliant, but this is unverified.
