| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
1,747 pcs
|
1747 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request | |
|
22 pcs
|
22 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Current | |
| Current Rating (Amps) | |
| DC Resistance (DCR) | |
| Height | |
| Inductance | |
| Length | |
| Material | |
| Mounting Type | |
| Operating Temperature | |
| SVHC Present | |
| Shielding | |
| Tolerance | |
| Type | |
| Width |
The 4922-07L is a fixed inductor manufactured by API Delevan Inc. It features a drum core, wirewound construction with a ferrite core material. This unshielded inductor has an inductance of 3.3 µH with a tolerance of ±15%.
It is rated for a continuous current of 3.23 A and has a maximum DC resistance (DCR) of 38 mOhm. The component is designed for surface mount assembly and comes in a nonstandard package with dimensions of 12.82 mm in length, 6.09 mm in width, and 5.84 mm in height.
The 4922-07L operates over a wide temperature range from -55°C to 125°C, making it suitable for demanding environments.
The inductance of the 4922-07L is 3.3 µH.
The current rating of the 4922-07L is 3.23 A.
The maximum DC resistance (DCR) of the 4922-07L is 38 mOhm.
The 4922-07L comes in a nonstandard surface mount package.
The operating temperature range of the 4922-07L is -55°C to 125°C.
The 4922-07L is an unshielded inductor.
The tolerance of the 4922-07L is ±15%.
