| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Ambient Temperature | |
| Approval Agency | |
| Breaker Type | |
| Current Rating | |
| Current Rating (Amps) | |
| Illumination | |
| Insulation Resistance | |
| Mounting Type | |
| Number of Poles | |
| Storage Temperature | |
| Tape & Reel | |
| Voltage Rating |
This E-T-A 482-G111-K1M1-A1S0-1A is a single-pole thermal circuit breaker, suitable for various applications including extra low voltage wiring systems in vehicles and process control.
It offers a current rating of 1A and a voltage rating of 230V AC. The breaker utilizes a thermal tripping mechanism with a characteristic curve of 1.15-1.4 times the nominal current (IN).
The device is designed for threadneck panel mounting with an M12x1 nickel-plated threadneck and includes a corrugated washer and hex nut. The main terminals are screw terminals with an M4 metric thread, fitted with flat head screws and a lock washer.
Key technical data includes an ambient temperature range of -55 to +75 °C, an interrupting capacity of up to 6,000 A DC / 1,000 A AC, and degrees of protection IP40 for the operating area and IP00 for the terminal area.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The current rating is 1A.
The voltage rating is 230V AC.
It is designed for threadneck panel mounting.
It features a push-pull plunger actuator.
The ambient temperature range is -55 to +75 °C.
Typical applications include extra low voltage wiring systems on all types of vehicles for land, sea and air, battery powered machines, and process control.
