4612X-102-181LF The Bourns 4612X-102-181LF is a resistor network with 6 isolated resistors, each rated at 180 Ohms with a ±2% tolerance. It is designed for through-hole mounting in a 12-SIP package.
Mfr Part #:

4612X-102-181LF

Available from 2 distributors
Mfr Name: Bourns
Bourns
The Bourns 4612X-102-181LF is a resistor network with 6 isolated resistors, each rated at 180 Ohms with a ±2% tolerance. It is designed for through-hole mounting in a 12-SIP package.
✓ Total Stock: 4,000 pcs
$ Price Range: $0.05

4612X-102-181LF Available from 2 distributors

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Non-Authorised Inventory information
2,000 pcs
2000 pcs On Request 1 On Request On Request On Request On Request On Request
Non-Authorised Inventory information
2,000 pcs
2000 pcs On Request 1 On Request On Request On Request On Request On Request

4612X-102-181LF Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Circuit Type
Height
Length
Mounting Type
Number of Pins
Number of Resistors
Operating Temperature
Power Per Element
Resistance (Ohms)
Supplier Device Package
Tape & Reel
Temperature Coefficient
Tolerance
Width

4612X-102-181LF Description

Short technical summary and product information.

This Bourns 4612X-102-181LF is a resistor network featuring 6 individual resistors within a single package. Each resistor offers a nominal resistance of 180 Ohms with a tight tolerance of ±2%. The network is configured as isolated circuits, providing flexibility in design.



The component operates within a temperature range of -55°C to 125°C and has a temperature coefficient of ±100ppm/°C. Each element can handle up to 300mW of power. The physical dimensions include a height of 5.08mm, a length of 30.43mm, and a width of 2.49mm.



Designed for through-hole mounting, this resistor network comes in a 12-SIP (Single In-line Package) configuration. It has 12 pins in total, facilitating easy integration into circuit boards. The RoHS status is compliant with RoHS3 standards, and it has an MSL rating of 1.

4612X-102-181LF Quick Information

Product Type: Resistor Network
Canonical Name: Bourns 4612X-102-181LF Resistor Network
Subcategory: Arrays

4612X-102-181LF Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

4612X-102-181LF Estimated Pricing

Qty Low High
1+ $0.05 $0.05

Estimated market price range - modelled values for guidance only, not live distributor offers.

4612X-102-181LF Features

  • Six isolated 180 Ohm resistors.
  • ±2% resistance tolerance.
  • Wide -55°C to 125°C operating temperature.
  • 300mW power per element.
  • Through-hole 12-SIP package.

4612X-102-181LF Applications

  • Ideal for general purpose circuit applications.
  • Suitable for signal conditioning circuits.
  • Used in power supply filtering stages.
  • Applicable in control system modules.

4612X-102-181LF FAQs

6 frequently asked questions generated from this part’s specifications.
What is the resistance value of the 4612X-102-181LF resistor network?

The resistance value is 180 Ohms.

What is the tolerance of the resistors in the 4612X-102-181LF network?

The tolerance is ±2%.

How many resistors are in the 4612X-102-181LF network?

There are 6 resistors in the network.

What is the operating temperature range for this resistor network?

The operating temperature range is -55°C to 125°C.

What type of package is the 4612X-102-181LF resistor network in?

It is in a 12-SIP package.

What is the mounting type for the 4612X-102-181LF?

The mounting type is Through Hole.
