Mfr Part #:

45240-600230

Name: 45240-600230
Brand: 3M
SKU: 45240-600230

Mfr Name: 3M

Description:

40P HDR ST VTH 30AU

Stock on Request

45240-600230 Description

Short technical summary and product information.

40P HDR ST VTH 30AU

Mfr Standard Lead Time: 12 weeks (varies by distributor)

RoHS Status: RoHS Compliant

Moisture Sensitivity Level (MSL): 1 Unlimited

REACH Status: REACH Unaffected

Same form/fit/function or matching attribute configuration across different manufacturers.

45240-620230

3M

40P HDR ST VTH LATCH 30AU

Category	Headers, Male Pins
Manufacturer Name	3M
Connector Type	Header
Contact Finish	Tin
Contact Finish Thickness	3.00碌in (0.076碌m)
Contact Length	0.094" (2.40mm)
Contact Material	Copper Alloy
Contact Shape	Square
Contact Type	Male Pin
Current Rating (Amps)	1A
Fastening Type	Push-Pull
Features	Keying Slot
Insulation Height	0.222" (5.64mm)
Insulation Material	Liquid Crystal Polymer (LCP)
Material Flammability Rating	UL94 V-0
Mounting Type	Through Hole
Number of Positions	40
Number of Positions Loaded	All
Number of Rows	2
Operating Temperature	-65°C ~ 125°C
Pitch	0.050" (1.27mm)
Row Spacing	0.050" (1.27mm)
Shrouding	Shrouded - 4 Wall
Style	Board to Cable/Wire
Termination	Solder
Voltage Rating	125VAC
