The TE Connectivity 446852-5 is a rectangular connector header designed for board-to-board or cable applications. It provides 165 positions arranged in 3 rows with a 2.54mm (0.100") pitch and matching row spacing, enabling high-density interconnections in compact electronic assemblies.
The header features a shrouded 4-wall design with a push-pull fastening type, along with a mating guide and mounting flange for secure and reliable connections. The contacts are male square pins made of brass with a tin-lead finish of 50.0µin (1.27µm) thickness, and each contact has a length of 3.56mm (0.140").
This component uses right angle through-hole mounting with solder termination, making it suitable for board edge applications where perpendicular connections are required. The insulator is molded from glass-filled polyphenylene sulfide (PPS) in a brown color, providing good thermal and mechanical stability.
All 165 positions are loaded, and the connector is designed for use in applications requiring robust, high-pin-count board-to-board or cable interconnections. The right angle orientation and board edge mounting style make it particularly useful in space-constrained designs where vertical space is limited.
| Qty | Low | High |
|---|---|---|
| 99+ | $655.47 | $655.47 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The 446852-5 has 165 positions arranged in 3 rows, with all positions loaded.
The pitch is 2.54mm (0.100") with matching 2.54mm row spacing.
It uses right angle through-hole mounting with solder termination, designed for board edge applications.
The contacts are brass square male pins with a tin-lead finish of 50.0µin (1.27µm) thickness.
The insulator is made of glass-filled polyphenylene sulfide (PPS) in brown color.
It includes a mating guide and mounting flange, with a shrouded 4-wall design and push-pull fastening.
