| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Breaker Type | |
| Current Rating (Amps) | |
| Illumination | |
| Illumination Voltage (Nominal) | |
| Insulation Resistance | |
| Mounting Type | |
| Number of Poles | |
| Storage Temperature | |
| Voltage Rating | |
| Weight |
The Schurter Inc. 4435.0508 is a 1-pole thermal circuit breaker designed for reliable circuit protection. It features a rocker actuation type and a panel mount configuration, making it suitable for various industrial and commercial applications.
This circuit breaker operates with a thermal tripping mechanism and has a rated current of 20A. It supports AC voltage ratings of 240 VAC (IEC) and 277 VAC (UL/CSA), as well as a DC voltage rating of 32 VDC. The device offers a conditional short circuit capacity of 2 kA at 240 VAC.
Key specifications include a mechanical lifetime of 50,000 switching cycles and electrical lifetimes of 30,000 cycles AC and 50,000 cycles DC. The operating temperature range is -30 °C to 60 °C. The ingress protection rating for the front side is IP40.
Applications for this circuit breaker include power tools, medical and laboratory equipment, industrial appliances, construction equipment, cleaning equipment, and commercial kitchen appliances. Its high configurability and finely graded rated currents make it a versatile component for demanding environments.
Rated for 240 VAC (IEC), 277 VAC (UL/CSA), and 32 VDC.
-30 °C to 60 °C.
2 kA at 240 VAC according to IEC 60934.
50,000 switching cycles.
30,000 switching cycles at 1x Ir, cos φ 0.6.
IP40 on the front side per IEC 60529.
Yes, it has a red illuminated actuator rated at 240V.
