| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Breaker Type | |
| Current Rating (Amps) | |
| Illumination | |
| Illumination Voltage (Nominal) | |
| Insulation Resistance | |
| Mounting Type | |
| Number of Poles | |
| Storage Temperature | |
| Voltage Rating | |
| Weight |
The Schurter Inc. 4435.0507 is a 1-pole thermal circuit breaker with a rocker actuation type. It is designed for panel mounting and offers a current rating range from 0.05 to 20A, with a specific rating of 16A. The device operates at 240 VAC IEC and 277 VAC UL/CSA, and 32 VDC.
Key technical specifications include a conditional short circuit capacity of 2 kA at 240 VAC, dielectric strength of over 2.5 kV, and insulation resistance greater than 100 MΩ at 500 VDC. It has a mechanical lifetime of 50,000 switching cycles and an operating temperature range of -30°C to 60°C.
This circuit breaker is suitable for various applications including power tools, medical and laboratory equipment, industrial appliances, and cleaning equipment. It offers a degree of protection of IP40 on the front side.
Additional features include a thermal tripping type and a weight of 16.5 - 18.5g. The illumination is red with a nominal voltage of 240V.
Rated voltage AC IEC 240V, AC UL/CSA 277V, DC 32V.
-30°C to 60°C.
Panel mount.
Thermal overcurrent protection.
16A continuous, with a range of 0.05 to 20A.
50,000 switching cycles mechanical.
IP40 (front side) according to IEC 60529.
