| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Breaker Type | |
| Current Rating (Amps) | |
| Illumination | |
| Illumination Voltage (Nominal) | |
| Industrial Grade | |
| Insulation Resistance | |
| Mounting Type | |
| Number of Poles | |
| Storage Temperature | |
| Voltage Rating | |
| Weight |
This Schurter Inc. 4435.0506 is a 1-pole thermal circuit breaker with a panel mount design. It offers a rated current range of 0.05 to 20 A and is suitable for AC and DC applications, with specific ratings of 240 VAC (IEC) and 32 VDC.
The breaker type is thermal, with a rocker actuation. Key electrical specifications include a conditional short circuit capacity of 2 kA at 240 VAC (IEC) and dielectric strength of over 2.5 kV (50 Hz) and 4 kV (1.2/50 μs impulse). Insulation resistance is rated at over 100 MΩ at 500 VDC.
Mechanical specifications include a lifetime of 50,000 switching cycles and a weight of 16.5-18.5 g. The operating temperature range is -30 °C to 60 °C, with storage temperatures from -40 °C to 60 °C. It also features vibration and shock resistance according to IEC standards.
Applications for this circuit breaker include power tools, medical and laboratory equipment, industrial appliances, and commercial kitchen appliances.
The rated voltage is 240 VAC for IEC and 277 VAC for UL/CSA, and 32 VDC.
The rated current range is 0.05 to 20 A AC.
This is a 1-pole circuit breaker.
The allowable operating temperature is -30 °C to 60 °C.
The degree of protection for the front side is IP40.
