| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Breaker Type | |
| Current Rating | |
| Current Rating (Amps) | |
| Illumination | |
| Illumination Voltage (Nominal) | |
| Insulation Resistance | |
| Mounting Type | |
| Number of Poles | |
| SVHC Present | |
| Storage Temperature | |
| Voltage Rating | |
| Weight |
The Schurter Inc. 4435.0505 is a 1-pole thermal circuit breaker designed for panel mounting. It features a rocker actuation and a thermal tripping type. The device operates with a rated AC voltage of 240 VAC (IEC) and 277 VAC (UL/CSA), and a rated DC voltage of 32 VDC.
This circuit breaker has a current rating of 8A and a rated current range of 0.05 to 20 A. It offers a conditional short circuit capacity of 2 kA at 240 VAC. The degree of protection for the front side is IP40.
Environmental specifications include an allowable operating temperature range of -30 °C to 60 °C and a storage temperature range of -40 °C to 60 °C. Mechanical specifications include a lifetime of 50,000 switching cycles and resistance to vibration and shock.
Applications for this circuit breaker include power tools, medical and laboratory equipment, industrial appliances, and cleaning equipment.
The circuit breaker is rated 240 VAC (IEC), 277 VAC (UL/CSA), and 32 VDC.
-30 °C to 60 °C.
Greater than 2.5 kV at 50 Hz and greater than 4 kV impulse 1.2/50 μs.
50,000 mechanical switching cycles.
IP40 on the front side per IEC 60529.
Panel mount.
