| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Breaker Type | |
| Current Rating (Amps) | |
| Illumination | |
| Illumination Voltage (Nominal) | |
| Insulation Resistance | |
| Mounting Type | |
| Number of Poles | |
| SVHC Present | |
| Storage Temperature | |
| Voltage Rating | |
| Weight |
This Schurter Inc. 4435.0504 is a 1-pole thermal circuit breaker with a rocker actuation type, suitable for panel mounting. It offers a rated current range of 0.05 to 20A AC and a nominal current rating of 6A. The device is designed for AC applications with a rated voltage of 240 VAC (IEC) and a unique UL/CSA rating of 277 VAC, along with a DC rating of 32 VDC.
Key electrical specifications include a conditional short circuit capacity of 2 kA at 240 VAC (IEC). The circuit breaker has a mechanical lifetime of 50,000 switching cycles and specific AC and DC lifetimes under load. It operates within a temperature range of -30°C to 60°C.
The ingress protection rating for the front side is IP40. The circuit breaker is built for reliability, with specified dielectric strength, insulation resistance, vibration resistance, and shock resistance. It is a thermal type breaker with positively trip-free release.
Applications for this circuit breaker include power tools, medical and laboratory equipment, industrial appliances, equipment for construction, cleaning equipment, and commercial and household kitchen appliances.
240 VAC (IEC), 277 VAC (UL/CSA), and 32 VDC.
-30 to 60 °C.
IP40 on the front side per IEC 60529.
>2.5 kV at 50 Hz and >4 kV impulse.
50,000 switching cycles.
Thermal.
Panel mount.
