| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Breaker Type | |
| Current Rating (Amps) | |
| Illumination | |
| Illumination Voltage (Nominal) | |
| Insulation Resistance | |
| Mounting Type | |
| Number of Poles | |
| Storage Temperature | |
| Voltage Rating | |
| Weight |
The Schurter Inc. 4435.0503 is a 1-pole thermal circuit breaker featuring a rocker actuation and panel mount design. It is rated for AC circuits up to 240 VAC (IEC) or 277 VAC (UL/CSA) and DC circuits up to 32 VDC.
This circuit breaker has a rated current range of 0.05 to 20 A and a conditional short circuit capacity of 2 kA at 240 VAC. It offers a mechanical lifetime of 50,000 switching cycles and electrical lifetimes of 30,000 cycles at AC and 50,000 cycles at DC.
Operating within a temperature range of -30 °C to 60 °C, the TA35 series breaker is built for demanding applications. Its robust construction ensures reliability in environments requiring protection against overloads and short circuits.
Key specifications include a degree of protection of IP40 on the front side, dielectric strength greater than 2.5 kV (50 Hz) and 4 kV (1.2/50 μs impulse), and insulation resistance greater than 100 MΩ at 500 VDC. The tripping type is thermal, and it has a weight of 16.5 - 18.5 g.
The rated current is 4A.
Rated for 240VAC (IEC), 277VAC (UL/CSA), and 32VDC.
-30 °C to 60 °C.
50,000 switching cycles.
IP40 acc. to IEC 60529.
Panel mount.
