| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Breaker Type | |
| Current Rating (Amps) | |
| Illumination | |
| Illumination Voltage (Nominal) | |
| Insulation Resistance | |
| Mounting Type | |
| Number of Poles | |
| Storage Temperature | |
| Voltage Rating | |
| Weight |
The Schurter Inc. 4435.0501 is a 1-pole thermal circuit breaker designed for reliable overcurrent protection. It offers a current rating of 2.5A and supports AC voltages up to 240V (IEC) or 277V (UL/CSA), and DC voltages up to 32V.
This breaker features a thermal tripping mechanism and a rocker actuation type, making it suitable for panel mount applications. Its technical specifications include a conditional short circuit capacity of 2 kA at 240 VAC, an IP40 degree of protection on the front side, and a wide operating temperature range of -30°C to 60°C.
The device has a mechanical lifetime of 50,000 switching cycles and electrical lifetimes that vary depending on AC or DC load conditions. It is designed for use in various industrial and commercial applications requiring robust circuit protection.
Key electrical characteristics include dielectric strength greater than 2.5 kV (50 Hz) and insulation resistance greater than 100 MΩ at 500 VDC. The Schurter 4435.0501 is built to withstand vibration and shock according to IEC standards.
The breaker is rated for 240 VAC (IEC), 277 VAC (UL/CSA), and 32 VDC.
The allowable operating temperature range is -30°C to 60°C.
The front side is rated IP40 according to IEC 60529.
The mechanical life is 50,000 switching cycles.
Dielectric strength is greater than 2.5 kV at 50 Hz and greater than 4 kV for impulse (1.2/50 μs).
