| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Breaker Type | |
| Current Rating (Amps) | |
| Illumination | |
| Illumination Voltage (Nominal) | |
| Insulation Resistance | |
| Mounting Type | |
| Number of Poles | |
| Storage Temperature | |
| Voltage Rating | |
| Weight |
This Schurter Inc. 4435.0499 is a thermal circuit breaker with a single pole configuration. It is designed for panel mounting and utilizes a rocker actuation mechanism. The breaker has a rated current of 500mA and a voltage rating of 240 VAC (IEC) and 277 VAC (UL/CSA), with a DC rating of 32 VDC.
Key electrical specifications include a conditional short circuit capacity of 2 kA at 240 VAC. The device offers a mechanical lifetime of 50,000 switching cycles and electrical lifetimes that vary based on AC or DC operation. It operates within a temperature range of -30 °C to 60 °C.
Applications for this circuit breaker include power tools, medical and laboratory equipment, industrial appliances, and commercial kitchen appliances. It provides reliable overcurrent protection in various industrial and commercial settings.
The rated voltage is 240 VAC per IEC and 277 VAC per UL/CSA.
The allowable operating temperature range is -30 °C to 60 °C.
It uses a rocker actuator with red illumination.
It is designed for panel mounting.
The front side is rated IP40 according to IEC 60529.
It is rated for a minimum of 50,000 mechanical switching cycles.
