| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Breaker Type | |
| Current Rating (Amps) | |
| Illumination | |
| Illumination Voltage (Nominal) | |
| Insulation Resistance | |
| Mounting Type | |
| Number of Poles | |
| Storage Temperature | |
| Voltage Rating | |
| Weight |
This Schurter Inc. 4435.0473 is a thermal circuit breaker designed for equipment protection. It features a 1-pole configuration with rocker actuation and a panel mount design for easy integration.
The circuit breaker has a rated current range of 0.05 to 20A AC and supports AC voltages of 240V (IEC) and 277V (UL/CSA), along with a DC voltage rating of 32VDC. It offers a conditional short circuit capacity of 2 kA at 240 VAC.
Key specifications include a mechanical lifetime of 50,000 switching cycles and electrical lifetimes of 30,000 cycles AC and 50,000 cycles DC. The operating temperature range is -30°C to 60°C.
Applications for this circuit breaker include power tools, medical and laboratory equipment, industrial appliances, and cleaning equipment.
The breaker is rated for 240VAC under IEC, 277VAC under UL/CSA, and 32VDC.
The allowable operating temperature is -30°C to 60°C.
The breaker is rated for 20A continuous current.
The tripping type is thermal.
The mechanical lifetime is 50,000 switching cycles.
The front side has IP40 protection according to IEC 60529.
