| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Breaker Type | |
| Current Rating (Amps) | |
| Illumination | |
| Illumination Voltage (Nominal) | |
| Insulation Resistance | |
| Mounting Type | |
| Number of Poles | |
| Operating Temperature | |
| Storage Temperature | |
| Voltage Rating | |
| Weight |
The Schurter Inc. 4435.0407 is a 2-pole thermal circuit breaker designed for reliable circuit protection. It offers a rated current of 7A and can handle AC voltages up to 240V and DC voltages up to 60V.
This circuit breaker features thermal tripping and a thermal-magnetic release mechanism for comprehensive short-circuit protection. It has a mechanical lifetime of 50,000 switching cycles and an operating temperature range of -30°C to 60°C. The device is designed for panel mounting and provides an IP40 degree of protection on the front side.
Key electrical specifications include a conditional short circuit capacity of 2 kA at 240 VAC, dielectric strength greater than 2.5 kV at 50 Hz, and impulse dielectric strength greater than 4 kV. Insulation resistance is rated above 100 MΩ at 500 VDC.
Applications for this circuit breaker include power tools, medical and laboratory equipment, industrial appliances, and equipment for construction. Its robust design and configurable options make it suitable for various industrial and commercial applications.
240 VAC (IEC) / 277 VAC (UL/CSA) and 60 VDC.
7 A continuous; AC range 0.05-20 A (magnetic up to 16 A).
-30 °C to 60 °C.
2 poles.
Thermal-magnetic.
50,000 switching cycles.
IP40 on front side (IEC 60529).
