The Schurter Inc. 4435.0372 is a 2-pole thermal circuit breaker from the TA35 series, suitable for various industrial applications. It offers a rated current of 1.5A and can handle AC voltages up to 240 VAC or DC voltages up to 60 VDC.
This circuit breaker features a thermal tripping type and a rocker actuation for easy operation. It is designed for panel mounting and has a snap-in version for secure installation. The device operates within an allowable temperature range of -30 °C to 60 °C.
Key electrical specifications include a conditional short circuit capacity of 2 kA at 240 VAC. The mechanical lifetime is rated for 50,000 switching cycles. The degree of protection on the front side is IP40.
Applications for this circuit breaker include power tools, medical and laboratory equipment, industrial appliances, and commercial kitchen appliances.
The rated voltage is 240 VAC (IEC), 277 VAC (UL/CSA), and 60 VDC.
The current rating is 1.5A.
It features rocker actuation.
The allowable operating temperature is from -30 °C to 60 °C.
The RoHS status is RoHS3 Compliant.
The MSL is 1 Unlimited.
