| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Breaker Type | |
| Current Rating (Amps) | |
| Illumination | |
| Illumination Voltage (Nominal) | |
| Insulation Resistance | |
| Mounting Type | |
| Number of Poles | |
| Storage Temperature | |
| Voltage Rating | |
| Weight |
The Schurter Inc. 4435.0367 is a thermal circuit breaker designed for equipment protection. This 2-pole device features rocker actuation and a panel mount configuration.
Key electrical specifications include a rated voltage of 240 VAC (IEC) or 277 VAC (UL/CSA) and 60 VDC. The rated current range is from 0.05A to 20A AC, with a magnetic trip capability up to 16A. It offers a conditional short circuit capacity of 2 kA at 240 VAC.
This circuit breaker operates within an allowable temperature range of -30°C to 60°C and has a mechanical lifetime of 50,000 switching cycles. It meets IP40 degree of protection on the front side and has a shock resistance of 30 G / 18 ms.
Applications for this circuit breaker include power tools, medical and laboratory equipment, industrial appliances, and commercial kitchen appliances.
240 VAC (IEC), 277 VAC (UL/CSA), and 60 VDC.
Panel mount.
-30°C to 60°C.
Thermal, with possible thermal-magnetic.
>2.5 kV at 50 Hz and >4 kV impulse (1.2/50 μs).
50,000 switching cycles under mechanical and electrical loads.
2 kA at 240 VAC per IEC 60934.
