| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Breaker Type | |
| Current Rating (Amps) | |
| Illumination | |
| Illumination Voltage (Nominal) | |
| Insulation Resistance | |
| Mounting Type | |
| Number of Poles | |
| Storage Temperature | |
| Voltage Rating | |
| Weight |
The Schurter Inc. 4435.0362 is a 2-pole thermal circuit breaker designed for reliable circuit protection. It offers a rated current of 2A and a voltage rating of 240 VAC (277 VAC UL/CSA) and 60 VDC.
This breaker features a thermal tripping type and a rocker actuation, providing a positive trip-free release. The device is designed for panel mounting and has a mechanical lifetime of 50,000 switching cycles. Its operating temperature range is -30 °C to 60 °C.
Applications for this circuit breaker include power tools, medical and laboratory equipment, industrial appliances, and commercial kitchen appliances. It is suitable for short-circuit protection with its magnetic release feature.
The rated voltage is 240 VAC (IEC) and 277 VAC (UL/CSA), with a DC rating of 60 VDC.
The rated current range AC is 0.05 - 20 A, with a magnetic rating up to 16 A. The specific rating for this part is 2A.
The allowable operating temperature is from -30 °C to 60 °C.
Yes, the RoHS status is RoHS3 Compliant.
The tripping type is Thermal, and it also supports Thermal-Magnetic tripping.
This circuit breaker has 2 poles.
