| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Breaker Type | |
| Current Rating | |
| Current Rating (Amps) | |
| Illumination | |
| Illumination Voltage (Nominal) | |
| Insulation Resistance | |
| Mounting Type | |
| Number of Poles | |
| Operating Temperature | |
| Storage Temperature | |
| Voltage Rating |
This Schurter Inc. 4435.0334 is a 2-pole thermal circuit breaker suitable for various industrial applications. It offers a rated current of 10A and operates at AC voltages up to 240 VAC and DC voltages up to 60 VDC.
The breaker features a rocker actuation type and a panel mount design for easy integration into equipment. It has a thermal tripping mechanism and a conditional short circuit capacity of 2 kA at 240 VAC. The operating temperature range is from -30 °C to 60 °C.
Key specifications include a mechanical lifetime of 50,000 switching cycles and an IP40 degree of protection on the front side. The device is designed for reliability in demanding environments.
Applications include power tools, medical and laboratory equipment, industrial appliances, and equipment for construction.
The rated AC voltage is 240 VAC (IEC) and 277 VAC (UL/CSA).
The rated DC voltage is 60 VDC.
The rated current range AC is 0.05 - 20 A.
The allowable operation temperature is -30 °C to 60 °C.
The mechanical lifetime is 50,000 switching cycles.
The tripping type is Thermal-Magnetic.
The mounting type is Panel Mount.
