| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Breaker Type | |
| Current Rating | |
| Current Rating (Amps) | |
| Illumination | |
| Illumination Voltage (Nominal) | |
| Insulation Resistance | |
| Mounting Type | |
| Number of Poles | |
| Operating Temperature | |
| Storage Temperature | |
| Voltage Rating | |
| Weight |
This Schurter Inc. 4435.0331 is a 2-pole thermal circuit breaker designed for reliable circuit protection. It offers a rated current of 8A and operates at up to 240 VAC or 60 VDC.
The breaker features a panel mount design for easy integration into equipment. It has a mechanical lifetime of 50,000 switching cycles and an operating temperature range of -30 °C to 60 °C.
Key electrical specifications include a conditional short circuit capacity of 2 kA at 240 VAC, dielectric strength of > 2.5 kV, and insulation resistance of > 100 MΩ. The degree of protection on the front side is IP40.
Applications for this circuit breaker include power tools, medical and laboratory equipment, industrial appliances, and commercial kitchen appliances.
The rated voltage is 240 VAC (IEC) and 277 VAC (UL/CSA), and 60 VDC.
The rated current is 8A.
This circuit breaker has 2 poles.
The allowable operation temperature is from -30 °C to 60 °C.
The RoHS status is RoHS3 Compliant.
The MSL is 1 Unlimited.
The REACH status is REACH Unaffected.
