| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Breaker Type | |
| Current Rating (Amps) | |
| Illumination | |
| Illumination Voltage (Nominal) | |
| Insulation Resistance | |
| Mounting Type | |
| Number of Poles | |
| Rated Current | |
| Storage Temperature | |
| Terminal | |
| Type | |
| Voltage Rating |
The Schurter Inc. 4435.0264 is a 2-pole thermal circuit breaker designed for reliable overcurrent protection. It offers a rated current of 6A and can handle AC voltages up to 240V and DC voltages up to 60V.
This circuit breaker features a thermal tripping mechanism and a rocker actuation type, providing a positively trip-free release. The device is designed for panel mounting and has a transparent button color. Its compact design and robust construction make it suitable for various industrial applications.
Key specifications include a conditional short circuit capacity of 2 kA at 240 VAC, an operating temperature range of -30°C to 60°C, and a mechanical lifetime of 50,000 switching cycles. The degree of protection on the front side is IP40.
Applications for this circuit breaker include power tools, medical and laboratory equipment, industrial appliances, and commercial kitchen appliances. Its configurability and reliability make it a versatile component for demanding environments.
240 VAC (IEC) or 277 VAC (UL/CSA) and 60 VDC.
-30 to 60 °C.
Panel mount with a 26x34mm cutout.
6 A.
2 poles.
50,000 switching cycles.
>2.5 kV at 50 Hz and >4 kV impulse.
