| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Breaker Type | |
| Current Rating (Amps) | |
| Illumination | |
| Illumination Voltage (Nominal) | |
| Mounting Type | |
| Number of Poles | |
| Voltage Rating |
This Schurter Inc. 4435.0262 is a 2-pole thermal circuit breaker designed for reliable circuit protection. It features rocker actuation and a panel mount type, making it suitable for various industrial applications. The breaker has a rated current of 10A and can handle AC voltages up to 240V and DC voltages up to 60V.
Key electrical specifications include a conditional short circuit capacity of 2 kA at 240 VAC. The device offers a mechanical lifetime of 50,000 switching cycles and electrical lifetimes of 50,000 cycles for both AC and DC operations under specified conditions. It operates within a temperature range of -30°C to 60°C.
Applications for this circuit breaker include power tools, medical and laboratory equipment, industrial appliances, and construction equipment. Its thermal tripping mechanism provides protection against overloads, while the option for thermal-magnetic tripping is available for short-circuit protection.
The Schurter 4435.0262 is rated for 240 VAC (IEC), 277 VAC (UL/CSA), and 60 VDC.
The allowable operating temperature range is -30 °C to 60 °C.
The mechanical lifetime is 50,000 switching cycles.
It uses a rocker actuator with blue illumination.
The front side has IP40 protection according to IEC 60529.
