| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Breaker Type | |
| Current Rating (Amps) | |
| Illumination | |
| Illumination Voltage (Nominal) | |
| Insulation Resistance | |
| Mounting Type | |
| Number of Poles | |
| Storage Temperature | |
| Voltage Rating | |
| Weight |
The Schurter Inc. 4435.0257 is a 1-pole thermal circuit breaker designed for equipment protection. It features a rocker actuation and a panel mount design.
Key electrical specifications include a rated AC voltage of 240 VAC (IEC) and 277 VAC (UL/CSA), and a rated DC voltage of 32 VDC. The current rating ranges from 0.05 to 20 A AC, with this specific model rated at 5A. It offers a conditional short circuit capacity of 2 kA at 240 VAC.
This circuit breaker operates within a temperature range of -30 °C to 60 °C and has a mechanical lifetime of 50,000 switching cycles. The tripping type is thermal, and it is designed for panel mounting.
Applications for this series include power tools, medical and laboratory equipment, industrial appliances, and commercial kitchen appliances.
The rated AC voltage is 240 VAC (IEC) or 277 VAC (UL/CSA).
The rated DC voltage is 32 VDC.
The current rating is 5 A continuous.
The allowable operating temperature range is -30 to 60 °C.
It uses a thermal tripping mechanism.
Mechanical lifetime is 50,000 switching cycles.
The front side offers IP40 protection according to IEC 60529.
