| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Breaker Type | |
| Current Rating (Amps) | |
| Insulation Resistance | |
| Mounting Type | |
| Number of Poles | |
| Storage Temperature | |
| Voltage Rating | |
| Weight |
The Schurter Inc. 4435.0252 is a 3-pole thermal circuit breaker designed for reliable circuit protection. It features a rocker actuation type and a panel mount for easy integration into equipment.
Key electrical specifications include a rated voltage of 240 VAC and a rated current range of 0.05 to 12 A, with this specific model rated at 1A. The breaker offers a conditional short circuit capacity of 2 kA @ 415 VAC. It is built with a thermal tripping mechanism and has a mechanical lifetime of 50,000 switching cycles.
Environmental and mechanical data includes an operating temperature range of -30 °C to 60 °C and a degree of protection of IP40 on the front side. The device also meets vibration resistance standards according to IEC 60068-2-6 and shock resistance standards according to IEC 60068-2-27.
Applications for this type of circuit breaker include power tools, medical and laboratory equipment, industrial appliances, and commercial kitchen appliances.
The rated voltage is 415Y / 240 VAC.
The rated current range is 0.05 to 12 A, with a nominal rating of 1 A.
The allowable operating temperature is -30 °C to 60 °C.
The degree of protection is IP40 according to IEC 60529.
The mechanical lifetime is 50,000 switching cycles.
The dielectric strength is greater than 2.5 kV at 50 Hz and greater than 4 kV for impulse 1.2/50 μs.
The insulation resistance is greater than 100 MΩ at 500 VDC.
