| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Breaker Type | |
| Current Rating (Amps) | |
| Illumination | |
| Illumination Voltage (Nominal) | |
| Insulation Resistance | |
| Mounting Type | |
| Number of Poles | |
| Storage Temperature | |
| Voltage Rating | |
| Weight |
The Schurter Inc. 4435.0239 is a 2-pole thermal circuit breaker suitable for panel mounting. It offers a rated current of 4A and can operate with AC voltages up to 240V or DC voltages up to 60V.
This circuit breaker utilizes thermal tripping for overload protection and is also capable of thermal-magnetic tripping for short-circuit protection. It has a mechanical lifetime of 50,000 switching cycles and an AC lifetime of 50,000 switching cycles at a power factor of 0.6.
Designed for industrial applications, the TA35 series breaker operates within a temperature range of -30°C to 60°C. Its degree of protection is IP40 on the front side, providing protection against solid objects larger than 1mm.
Key electrical specifications include a dielectric strength of over 2.5 kV and an impulse dielectric strength of over 4 kV. The insulation resistance is rated at over 100 MΩ at 500 VDC. The breaker has a weight of 32g.
Rated for 240VAC and 60VDC.
-30°C to 60°C.
Panel mount with bulk packaging.
Thermal-Magnetic.
2 poles.
Rocker actuator.
Yes, clear illumination at 120V nominal.
