The Schurter Inc. 4435.022 is a 2-pole thermal circuit breaker designed for reliable circuit protection. It offers a rated current of 6A and can handle AC voltages up to 240V and DC voltages up to 60V.
This circuit breaker features thermal tripping and a rocker actuation type, making it suitable for panel mounting. Its technical specifications include a conditional short circuit capacity of 2 kA at 240 VAC and an operating temperature range of -30°C to 60°C.
Applications for this component include power tools, medical and laboratory equipment, industrial appliances, and equipment for construction. The device is built to withstand mechanical stress with a lifetime of 50,000 switching cycles.
Key electrical characteristics include a dielectric strength of over 2.5 kV at 50 Hz and an insulation resistance greater than 100 MΩ at 500 VDC. The degree of protection on the front side is IP40.
6A.
240 VAC (IEC), 277 VAC (UL/CSA), and 60 VDC.
Thermal-magnetic.
2 poles.
-30 °C to 60 °C.
Panel mount.
50,000 switching cycles.
