| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Breaker Type | |
| Current Rating | |
| Current Rating (Amps) | |
| Insulation Resistance | |
| Mounting Type | |
| Number of Poles | |
| Operating Temperature | |
| Storage Temperature | |
| Voltage Rating | |
| Weight |
The Schurter Inc. 4435.0211 is a 2-pole thermal circuit breaker suitable for a wide range of applications including power tools, medical equipment, and industrial appliances. It offers thermal-magnetic tripping and a rocker actuation type, with a panel mount design for easy integration.
Key electrical specifications include a rated AC voltage of 240 VAC (277 VAC UL/CSA) and a rated DC voltage of 60 VDC. The current rating is 500mA, with a rated current range up to 20A AC. It provides a conditional short circuit capacity of 2 kA at 240 VAC.
This circuit breaker is built for durability, featuring a mechanical lifetime of 50,000 switching cycles. It operates within a temperature range of -30°C to 60°C and meets IEC standards for vibration and shock resistance. The degree of protection on the front side is IP40.
Applications for this device include industrial appliances, equipment for construction, cleaning equipment, and commercial kitchen appliances. Its robust design and reliable performance make it a suitable choice for demanding environments.
240 VAC (IEC) and 277 VAC (UL/CSA) for AC, and 60 VDC for DC.
-30 °C to 60 °C.
0.5 A to 20 A AC.
Thermal-magnetic.
Panel mount.
IP40 front side according to IEC 60529.
50,000 cycles for both mechanical and electrical (AC and DC) operations.
