| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Breaker Type | |
| Current Rating (Amps) | |
| Illumination | |
| Illumination Voltage (Nominal) | |
| Insulation Resistance | |
| Mounting Type | |
| Number of Poles | |
| Storage Temperature | |
| Voltage Rating | |
| Weight |
The Schurter Inc. 4435.0182 is a 1-pole thermal circuit breaker designed for reliable overcurrent protection. It operates with a rated voltage of 240 VAC (IEC) or 277 VAC (UL/CSA) and 32 VDC, with a current rating range from 0.05 to 20 A. This breaker features a thermal tripping type and rocker actuation, providing a positively trip-free release.
With a mechanical lifetime of 50,000 switching cycles and electrical lifetimes of 30,000 cycles AC and 50,000 cycles DC, the 4435.0182 is built for durability. It can withstand operating temperatures from -30 °C to 60 °C and meets IP40 protection on the front side.
This circuit breaker is suitable for a wide range of applications, including power tools, medical and laboratory equipment, industrial appliances, and cleaning equipment. Its panel mount design ensures easy integration into various systems.
AC: 240 VAC (IEC) or 277 VAC (UL/CSA); DC: 32 VDC.
15 A nominal, with a range of 0.05 to 20 A.
-30°C to 60°C.
Panel mount.
Thermal.
Rocker with green illumination.
50,000 switching cycles.
