| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Breaker Type | |
| Current Rating | |
| Current Rating (Amps) | |
| Illumination | |
| Illumination Voltage (Nominal) | |
| Insulation Resistance | |
| Mounting Type | |
| Number of Poles | |
| Storage Temperature | |
| Voltage Rating | |
| Weight |
The Schurter 4435.0181 is a 1-pole thermal circuit breaker designed for reliable overcurrent protection. It features a rocker actuation type and panel mount for easy integration into equipment.
This circuit breaker operates with a rated voltage of 240 VAC (IEC) and 277 VAC (UL/CSA), and a DC voltage rating of 32 VDC. The AC current range is from 0.05 to 20 A, with this specific model rated at 10A. It offers a conditional short circuit capacity of 2 kA at 240 VAC.
Key technical specifications include a thermal tripping type, mechanical lifetime of 50,000 cycles, and an operating temperature range of -30 °C to 60 °C. The device has a degree of protection of IP40 on the front side.
Applications for this circuit breaker include power tools, medical and laboratory equipment, industrial appliances, and cleaning equipment. Its robust design and specific ratings make it suitable for demanding environments.
The circuit breaker is rated for 240 VAC (IEC), 277 VAC (UL/CSA), and 32 VDC.
Panel mount.
-30 to 60 °C.
10A.
>2.5 kV at 50 Hz.
50,000 switching cycles.
