| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Breaker Type | |
| Current Rating (Amps) | |
| Illumination | |
| Illumination Voltage (Nominal) | |
| Insulation Resistance | |
| Mounting Type | |
| Number of Poles | |
| Storage Temperature | |
| Voltage Rating | |
| Weight |
The Schurter Inc. 4435.0166 is a 3-pole thermal circuit breaker designed for equipment protection. It offers a rated current range of 0.05 to 12A AC and a rated voltage of 240 VAC.
This circuit breaker features thermal tripping and rocker actuation, with a panel mount type. It has a mechanical lifetime of 50,000 switching cycles and an operating temperature range of -30°C to 60°C. The device also includes illumination with a blue rocker and a nominal illumination voltage of 415V.
Applications for this circuit breaker include power tools, medical and laboratory equipment, industrial appliances, and commercial kitchen appliances. It has a conditional short circuit capacity of 2 kA at 415 VAC and meets IP40 degree of protection on the front side.
415 VAC (Y configuration) and 240 VAC.
-30°C to 60°C.
2 kA at 415 VAC.
50,000 switching cycles for both mechanical and AC/DC operation.
>2.5 kV at 50 Hz and >4 kV impulse (1.2/50 μs).
Panel mount.
Rocker actuator.
