| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Breaker Type | |
| Current Rating | |
| Current Rating (Amps) | |
| Illumination | |
| Illumination Voltage (Nominal) | |
| Insulation Resistance | |
| Mounting Type | |
| Number of Poles | |
| Operating Temperature | |
| Storage Temperature | |
| Voltage Rating | |
| Weight |
The Schurter Inc. 4435.0165 is a 2-pole thermal circuit breaker designed for reliable circuit protection. It offers a rated current of 3A and a voltage rating of 240VAC (UL/CSA 277VAC) and 60VDC.
This circuit breaker features a thermal tripping mechanism and a rocker actuation type. It has a mechanical lifetime of 50,000 switching cycles and an operating temperature range of -30°C to 60°C. The device is suitable for panel mounting.
Key electrical specifications include a conditional short circuit capacity of 2 kA at 240 VAC and an insulation resistance greater than 100 MΩ at 500 VDC. The degree of protection on the front side is IP40.
Applications for this circuit breaker include power tools, medical and laboratory equipment, industrial appliances, and commercial kitchen appliances.
Rated for 240VAC (IEC) or 277VAC (UL/CSA) and 60VDC.
Panel mount.
-30°C to 60°C.
3A.
2 poles.
50,000 switching cycles.
Rocker actuator.
