| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Breaker Type | |
| Current Rating | |
| Current Rating (Amps) | |
| Illumination | |
| Illumination Voltage (Nominal) | |
| Insulation Resistance | |
| Mounting Type | |
| Number of Poles | |
| SVHC Present | |
| Storage Temperature | |
| Voltage Rating | |
| Weight |
The Schurter Inc. 4435.0164 is a thermal circuit breaker designed for reliable circuit protection. This 2-pole device operates with a rated current of 10A and a voltage rating of 240VAC (277VAC UL/CSA) and 60VDC.
Key technical specifications include a conditional short circuit capacity of 2 kA at 240 VAC, an IP40 degree of protection on the front side, and a wide operating temperature range of -30°C to 60°C. The breaker offers a mechanical lifetime of 50,000 switching cycles.
Featuring a rocker actuation type, this circuit breaker is designed for panel mounting. Its tripping type is thermal-magnetic, providing robust protection against overloads and short circuits. The unit has a weight of 32g without the magnetic module and 56g with it.
Applications for this circuit breaker include power tools, medical and laboratory equipment, industrial appliances, and equipment for construction, cleaning, and commercial kitchens.
The breaker is rated for 240 VAC and 277 VAC (UL/CSA) as well as 60 VDC.
The allowable operating temperature is -30°C to 60°C.
It is a panel mount circuit breaker with a rocker actuator.
The continuous current rating is 10 A, with a trip range of 0.05 A to 20 A AC (magnetic up to 16 A).
It uses a thermal-magnetic tripping mechanism.
The front side is rated IP40 according to IEC 60529.
The mechanical lifetime is 50,000 switching cycles.
