| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Breaker Type | |
| Current Rating (Amps) | |
| Insulation Resistance | |
| Mounting Type | |
| Number of Poles | |
| Storage Temperature | |
| Voltage Rating | |
| Weight |
The Schurter Inc. 4435.0152 is a thermal circuit breaker with a 1-pole configuration, suitable for supplementary protection in general industrial applications. It offers a rated voltage of 240 VAC (IEC) or 277 VAC (UL/CSA) and a DC voltage rating of 32 VDC. The current rating ranges from 0.05 to 20 A.
This circuit breaker features a positively trip-free release mechanism and operates according to IEC standard S-type. The actuation is via a rotary knob, designed for easy operation even with gloves. It has a mechanical lifetime of 50,000 switching cycles and meets IEC overload trip requirements.
Designed for panel mounting, the 4435.0152 has a degree of protection of IP40 on the front side. Its operating temperature range is -30 °C to 60 °C. The part is also noted as being phase-out, with last order dates in 2023 and early 2024.
Approvals include VDE, UL UR, and CCC, indicating compliance with various safety standards. This component is intended for use in industrial environments.
The rated voltage is 240 VAC (IEC) and 277 VAC (UL/CSA), with a DC rating of 32 VDC.
The rated current range is 0.05 to 20 A.
It uses rotary knob actuation.
The allowable operation temperature is from -30 °C to 60 °C.
The mechanical lifetime is 50,000 switching cycles.
Approvals include VDE, UL UR, and CCC.
