| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Breaker Type | |
| Current Rating (Amps) | |
| Insulation Resistance | |
| Mounting Type | |
| Number of Poles | |
| Storage Temperature | |
| Voltage Rating | |
| Weight |
The Schurter Inc. 4435.0128 is a 2-pole thermal circuit breaker suitable for various industrial applications. It offers a rated current range of 0.05 to 20 A AC and a magnetic trip capability up to 16 A. The breaker operates with a rated voltage of 240 VAC (IEC) or 277 VAC (UL/CSA) and 60 VDC.
Designed for panel mounting, this circuit breaker features a rocker actuation type and a thermal-magnetic tripping mechanism. It has a mechanical lifetime of 50,000 switching cycles and meets specific overload trip requirements for both IEC and UL/CSA standards. The operating temperature range is -30 °C to 60 °C.
Key electrical specifications include a conditional short circuit capacity of 2 kA at 240 VAC. Environmental considerations include a front-side degree of protection of IP40. The device also boasts high dielectric strength and insulation resistance values, ensuring reliable operation.
Applications for this circuit breaker include power tools, medical and laboratory equipment, industrial appliances, and commercial kitchen appliances.
The rated voltage is 240 VAC (IEC) and 277 VAC (UL/CSA), with a DC rating of 60 VDC.
The rated current range is 0.05 to 20 A AC, with a magnetic trip capability up to 16 A.
It uses a rocker actuation type.
The allowable operation temperature is from -30 °C to 60 °C.
It has 2 poles.
