| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Breaker Type | |
| Current Rating (Amps) | |
| Insulation Resistance | |
| Mounting Type | |
| Number of Poles | |
| Operating Temperature | |
| SVHC Present | |
| Storage Temperature | |
| Voltage Rating | |
| Weight |
The Schurter Inc. 4435.0123 is a 2-pole thermal circuit breaker designed for general industrial use. It offers a rated voltage of 240 VAC (IEC) or 277 VAC (UL/CSA) and a DC voltage rating of 60 VDC. The current rating ranges from 0.05 A to 20 A.
This circuit breaker features a positively trip-free release and a thermal tripping mechanism with rotary knob actuation. It has a mechanical lifetime of 50,000 switching cycles and an electrical lifetime of 50,000 cycles under specified AC and DC conditions. The operating temperature range is -30 °C to 60 °C.
Designed for panel mounting, the Schurter 4435.0123 provides a degree of protection of IP40 on the front side. Its applications include power tools, industrial appliances, construction equipment, cleaning equipment, and commercial/household kitchen appliances.
Approvals include VDE, UL, and CCC, indicating compliance with relevant safety standards. The device has a conditional short circuit capacity of 2 kA at 240 VAC.
The circuit breaker is rated for 240VAC (IEC), 277VAC (UL/CSA), and 60VDC.
Panel mount.
-30°C to 60°C.
Thermal.
