| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Breaker Type | |
| Current Rating (Amps) | |
| Insulation Resistance | |
| Mounting Type | |
| Number of Poles | |
| SVHC Present | |
| Storage Temperature | |
| Voltage Rating |
The Schurter Inc. 4435.0119 is a thermal circuit breaker designed for reliable circuit protection. This 3-pole unit offers a current rating range of 0.05 to 12A and a rated voltage of up to 415 VAC / 240 VAC. It features a positively trip-free release mechanism and rocker actuation for ease of use.
With a conditional short circuit capacity of 2 kA @ 415 VAC and a degree of protection of IP40 on the front side, this circuit breaker is suitable for various industrial applications. It has a mechanical lifespan of 50,000 switching cycles and operates within a temperature range of -30°C to 60°C.
The breaker is designed for panel mounting and includes thermal tripping. Its robust construction ensures durability in demanding environments. Approvals include VDE, UL, and CCC, indicating compliance with international safety standards.
The rated voltage is 415 VAC (Y) / 240 VAC.
-30 °C to 60 °C.
The rated current is 6 A, with a range of 0.05 to 12 A.
2 kA at 415 VAC per IEC 60934.
50,000 switching cycles for mechanical, AC, and DC operations.
IP40 on the front side per IEC 60529.
Panel mount with rocker actuation.
