| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Breaker Type | |
| Current Rating (Amps) | |
| Illumination | |
| Illumination Voltage (Nominal) | |
| Insulation Resistance | |
| Mounting Type | |
| Number of Poles | |
| Storage Temperature | |
| Voltage Rating |
The Schurter Inc. 4435.0106 is a 2-pole thermal circuit breaker designed for reliable circuit protection. It offers a rated current of 15A and operates at up to 240VAC or 60VDC. The breaker features a thermal tripping type and a thermal-magnetic tripping capability, ensuring protection against overloads and short circuits.
With a panel mount design and rocker actuation, this circuit breaker is suitable for various applications. It has a mechanical lifetime of 50,000 switching cycles and electrical lifetimes of 50,000 cycles under AC and DC conditions. The operating temperature range is -30°C to 60°C.
Applications for this circuit breaker include power tools, medical and laboratory equipment, industrial appliances, and equipment for construction. Its robust design and compliance with IEC standards make it a dependable choice for demanding environments.
The breaker is rated for 240 VAC (IEC), 277 VAC (UL/CSA), and 60 VDC.
The operating temperature range is -30°C to 60°C.
The dielectric strength is >2.5 kV at 50 Hz and >4 kV impulse (1.2/50 μs).
The mechanical lifetime is 50,000 switching cycles.
The front side protection is IP40 acc. to IEC 60529.
It is panel mount.
