| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Breaker Type | |
| Current Rating (Amps) | |
| Illumination | |
| Illumination Voltage (Nominal) | |
| Insulation Resistance | |
| Mounting Type | |
| Number of Poles | |
| Storage Temperature | |
| Voltage Rating | |
| Weight |
The Schurter Inc. 4435.0105 is a 2-pole thermal circuit breaker suitable for various industrial applications. It features a rocker actuation type and is designed for panel mounting.
Key electrical specifications include a rated voltage of 240 VAC (IEC) or 277 VAC (UL/CSA) and 60 VDC. The rated current range is from 0.05 A to 20 A, with a magnetic trip capability up to 16 A. The breaker offers a conditional short circuit capacity of 2 kA at 240 VAC.
Environmental and mechanical specifications include an operating temperature range of -30 °C to 60 °C and a degree of protection of IP40 on the front side. The device has a mechanical lifetime of 50,000 switching cycles.
Applications for this circuit breaker include power tools, medical and laboratory equipment, industrial appliances, and commercial kitchen appliances.
The rated current is 1A.
It is rated for 240VAC (IEC), 277VAC (UL/CSA), and 60VDC.
The allowable operating temperature range is -30°C to 60°C.
It uses a rocker actuator.
It has 2 poles.
The front side is rated IP40 according to IEC 60529.
