| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Approval Agency | |
| Breaker Type | |
| Current Rating | |
| Current Rating (Amps) | |
| Insulation Resistance | |
| Mounting Type | |
| Number of Poles | |
| Operating Temperature | |
| Storage Temperature | |
| Voltage Rating |
The Schurter Inc. 4435.009 is a thermal circuit breaker designed for equipment protection. This 2-pole device features a rocker actuation type and is suitable for panel mounting.
Key electrical specifications include a rated voltage of 240 VAC (IEC) and 277 VAC (UL/CSA), with a DC rating of 60 VDC. The rated current range is from 0.05 to 20A AC, with a magnetic trip capability up to 16A. It offers a conditional short circuit capacity of 2 kA at 240 VAC.
Environmental and mechanical data indicate an operating temperature range of -30°C to 60°C and a storage temperature range of -40°C to 60°C. The circuit breaker has a mechanical lifetime of 50,000 switching cycles and meets IP40 degree of protection on the front side.
Applications for this type of circuit breaker include power tools, medical and laboratory equipment, industrial appliances, and commercial kitchen appliances. It provides reliable short-circuit protection with its thermal-magnetic tripping mechanism.
It is rated for 240VAC (IEC) and 277VAC (UL/CSA) for AC, and 60VDC for DC.
-30°C to 60°C.
Panel mount.
8A.
Thermal-magnetic.
CSA C22.2 No 235, EN 60934, GB 17701, IEC 60934, UL1077.
50,000 cycles.
