The Schurter Inc. TA35 series thermal circuit breaker, part number 4435.005, is a 3-pole device designed for general industrial use. It features a rocker actuation type and snap-in mounting for easy installation.
This circuit breaker operates thermally and is rated for AC voltages up to 415Y/240 VAC. The rated current range is specified as 0.05 to 12 A according to the datasheet, though the product data lists a specific rating of 10A. It has a conditional short-circuit capacity of 2 kA at 415 VAC.
Environmental specifications include a degree of protection of IP40 on the front side. The device can withstand dielectric strength of >2.5 kV at 50 Hz and >4 kV impulse. Insulation resistance is rated at >100 MΩ at 500 VDC. The operating temperature range is -30 °C to 60 °C.
Applications for this circuit breaker include power tools, medical and laboratory equipment, industrial appliances, and commercial kitchen appliances. It meets standards such as IEC 60934, UL1077, and CSA C22.2 235.
240VAC line-to-neutral or 415VAC Y.
Panel mount.
-30°C to 60°C.
10A.
3 poles.
CSA C22.2 No 235, EN 60934, GB 17701, IEC 60934, UL1077.
50,000 switching cycles.
