| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Approval Agency | |
| Breaker Type | |
| Current Rating | |
| Current Rating (Amps) | |
| Industrial Grade | |
| Insulation Resistance | |
| Mounting Type | |
| Number of Poles | |
| Operating Temperature | |
| Storage Temperature | |
| Voltage Rating |
The Schurter Inc. 4435.004 is a 2-pole thermal circuit breaker designed for panel mounting. It features a rated current of 7A and can operate at AC voltages up to 240 VAC and DC voltages up to 60 VDC.
This circuit breaker offers thermal tripping and is suitable for various industrial applications. It has a mechanical lifetime of 50,000 switching cycles and meets IEC and UL/CSA standards for overload conditions.
Key technical data includes a conditional short circuit capacity of 2 kA at 240 VAC, an operating temperature range of -30 °C to 60 °C, and an insulation resistance of over 100 MΩ. The degree of protection on the front side is IP40.
Applications for this type of circuit breaker include power tools, medical and laboratory equipment, industrial appliances, and equipment for construction. Its robust design ensures reliable protection in demanding environments.
The Schurter 4435.004 is rated for 240 VAC (IEC), 277 VAC (UL/CSA), and 60 VDC.
The operating temperature range is -30 °C to 60 °C.
The 4435.004 uses a thermal-magnetic tripping mechanism.
The rated current is 7A AC, with a rated current range of 0.05 A to 20 A for thermal tripping and up to 16 A for magnetic tripping.
The degree of protection is IP40 according to IEC 60529.
The mechanical lifetime is 50,000 switching cycles.
