| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Breaker Type | |
| Current Rating (Amps) | |
| Insulation Resistance | |
| Mounting Type | |
| Number of Poles | |
| Storage Temperature | |
| Terminal | |
| Voltage Rating |
This Schurter Inc. 4435.0024 is a 2-pole thermal circuit breaker suitable for various industrial applications. It offers a rated current range from 0.05A to 20A AC and up to 16A magnetically. The breaker operates with a nominal AC voltage of 240 VAC and a DC voltage of 60 VDC.
Designed for panel mounting, this rocker-actuated device has a mechanical lifetime of 50,000 switching cycles. It operates within a temperature range of -30°C to 60°C and meets IP40 protection standards on the front side. The circuit breaker provides short-circuit protection and is built for reliability in demanding environments.
Key electrical specifications include a conditional short circuit capacity of 2 kA at 240 VAC, dielectric strength of over 2.5 kV (50 Hz), and insulation resistance greater than 100 MΩ at 500 VDC. It also features specific overload trip counts for IEC and UL/CSA standards.
Applications for this circuit breaker include power tools, medical and laboratory equipment, industrial appliances, and commercial kitchen appliances. Its robust construction and thermal-magnetic tripping mechanism ensure effective circuit protection.
The rated voltage is 240 VAC (IEC) and 277 VAC (UL/CSA), with a DC rating of 60 VDC.
The rated current range is 0.05A to 20A AC, with a magnetic range up to 16A.
The allowable operating temperature is from -30°C to 60°C.
Yes, the RoHS status is RoHS3 Compliant.
It uses panel mount.
It has 2 poles.
The tripping type is Thermal-Magnetic.
