The Schurter Inc. 4430.359 is a thermal circuit breaker designed for reliable overload protection. This 2-pole device offers a rated current of 5A and a voltage rating of 240VAC (60VDC).
Key features include rocker actuation for easy operation and a panel mount design for convenient integration into equipment. The circuit breaker provides a conditional short circuit capacity of 1 kA at 240VAC and a short circuit capacity of 300A. It has a mechanical lifetime of 50,000 switching cycles.
With a degree of protection of IP40 on the front side, this circuit breaker is suitable for various industrial applications. The operating temperature range is -10°C to 55°C, and it meets stringent dielectric strength and insulation resistance requirements.
Applications for this thermal circuit breaker include power tools, industrial appliances, power supplies, and equipment for construction and cleaning.
It is rated for 240VAC and 60VDC operation.
The allowable operating temperature range is -10°C to 55°C.
The rated current is 5A.
It uses a thermal tripping mechanism.
IP40 on the front side, and IP54 with the factory-mounted protection cover.
It has 2 poles.
The dielectric strength is 4kVAC.
