| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Approval Agency | |
| Breaker Type | |
| Current Rating (Amps) | |
| Insulation Resistance | |
| Mounting Type | |
| Number of Poles | |
| Storage Temperature | |
| Tape & Reel | |
| Voltage Rating | |
| Weight |
The Schurter Inc. 4430.3513 is a 2-pole thermal circuit breaker designed for reliable overload protection in various applications. It features a panel mount design for easy integration into equipment.
Key electrical specifications include a rated AC voltage of 240 VAC and a rated DC voltage of 60 VDC. The rated current range is from 0.05 A to 20 A. This thermal breaker offers a conditional short circuit capacity of 1 kA at 240 VAC and an Icn of 300A at 240 VAC for currents 3A or greater.
Environmental and mechanical specifications include a degree of protection of IP40 on the front side, which can be increased to IP54 with a factory-mounted protection cover. The operating temperature range is -10 °C to 55 °C. The breaker has a mechanical lifetime of 50,000 switching cycles.
Applications for this circuit breaker include power tools, industrial appliances, power supplies, and equipment for construction and cleaning.
The operating voltage is 240 VAC and 60 VDC.
-10°C to 55°C.
20A continuous.
Thermal tripping.
CSA C22.2 No 235, EN 60934, GB 17701, IEC 60934, UL1077.
2-pole.
Panel mount.
