| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Approval Agency | |
| Breaker Type | |
| Current Rating (Amps) | |
| Insulation Resistance | |
| Mounting Type | |
| Number of Poles | |
| Storage Temperature | |
| Voltage Rating | |
| Weight |
The Schurter Inc. 4430.3424 is a thermal circuit breaker designed for reliable overload protection in various applications. This 2-pole unit features a pushbutton actuator and a panel mount design for easy integration into equipment.
With a current rating of 10A, it is suitable for circuits operating at up to 240 VAC or 60 VDC. The breaker offers a tripping type of thermal, ensuring protection against overcurrent conditions through heat.
Key specifications include a mechanical lifetime of 50,000 switching cycles and an operating temperature range of -10°C to 55°C. The device also provides a degree of protection of IP40 on the front side.
Applications for this circuit breaker include power tools, industrial appliances, power supplies, and equipment for construction and cleaning.
10 A
240 VAC and 60 VDC
Thermal circuit breaker with thermal tripping
2 poles
-10 °C to 55 °C
UL1077, IEC60934, CSA C22.2 No 235, EN 60934, GB 17701
IP40
