| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Breaker Type | |
| Current Rating | |
| Current Rating (Amps) | |
| Insulation Resistance | |
| Mounting Type | |
| Number of Poles | |
| Storage Temperature | |
| Voltage Rating |
The Schurter Inc. 4430.3416 is a 2-pole thermal circuit breaker with a current rating of 3A and a voltage rating of 240VAC / 60VDC. It is designed for panel mounting and features a rocker actuation type.
This circuit breaker offers thermal overload protection with a positively trip-free release. It has a mechanical lifetime of 50,000 switching cycles and an operating temperature range of -10°C to 55°C. The device provides a conditional short circuit capacity of 1 kA at 240VAC and a short circuit capacity of up to 300A.
Applications for this circuit breaker include power tools, industrial appliances, power supplies, equipment for construction, and cleaning equipment. It meets IP40 degree of protection on the front side, which can be extended to IP54 with a factory-mounted protection cover. The dielectric strength is 4 kVAC and insulation resistance is greater than 100 MΩ at 500 VDC.
240 VAC and 60 VDC.
3 A.
-10 to 55 °C.
2 poles.
IP40 without cover, IP54 with cover.
Thermal.
50,000 switching cycles.
